ECS X79R-A Motherboard At Computex 2011 - Pictures Inside!

Post by Apoptosis » Tue May 31, 2011 9:52 am

We just received some pictures of the ECS X79R-A motherboard form the ECS booth over at Computex 2011 that are worth a forum post. These new boards look pretty cool. Take a look at the dual lever CPU socket that is being used for LGA2011. That CPU isn't going any place!
Find us on Facebook to discover the faces behind the names!
Follow Me on Twitter!

CaptChuck
Legit Enthusiast
Legit Enthusiast
Posts: 42
Joined: Thu Aug 31, 2006 10:41 pm
Location: Redding Calif.

Re: ECS X79R-A Motherboard At Computex 2011 - Pictures Insid

Post by CaptChuck » Tue May 31, 2011 11:08 am

Split Memory slots...Interesting.
Win 7 Home
Intel i5 3570K
Antec Kuhler 620 CPU cooler
CORSAIR Enthusiast Series TX750 V2 750W PS
Asus P77-V LE
16GB Corsair DDR3-1600 RAM
Sapphire HD 7970 OC
Asus Xonar DS 7.1 Sound Card
Seagate Barracuda 1 TB SATA II HD
LG DVD
Asus DVD RW

DragonFury
Legit Extremist
Legit Extremist
Posts: 605
Joined: Mon Jan 31, 2011 11:51 am

Re: ECS X79R-A Motherboard At Computex 2011 - Pictures Insid

Post by DragonFury » Tue May 31, 2011 1:49 pm

interesting layout. I like the color scheme. Any word on the release of the X79 ?
Mini ME
Is in a state of flux....

User avatar
bubba
Staff Writer
Staff Writer
Posts: 4692
Joined: Sun May 01, 2005 10:24 am
Location: STL

Re: ECS X79R-A Motherboard At Computex 2011 - Pictures Insid

Post by bubba » Tue May 31, 2011 9:11 pm

This board is going to make case selection easy, nothing with a shallow depth that is for sure. With the CPU that far forward on the board, and fat heatsink like the Noctua NH-D14, you will be very close to the back of the optical drives on a shallow depth case.

Integrated backing plate to the socket, that's gonna be different. I want to see the back side of that socket.

Gonna be interesting. :-k
"The democracy will cease to exist when you take away from those who are willing to work and give to those who would not."
-Thomas Jefferson

User avatar
skier
Moderator
Moderator
Posts: 4450
Joined: Mon Mar 26, 2007 3:29 pm
Location: Maine
Contact:

Re: ECS X79R-A Motherboard At Computex 2011 - Pictures Insid

Post by skier » Fri Jun 10, 2011 10:00 am

i'd replace the grey colors with black

socket layout is different but logical considering the perpetual question of 'will it hit my RAM'
-Austin
Screamin' BCLK: Image
775 System (Overclocking Platform): Q8400/Q8300/E8400/E7400/E7500 - GA-EP45-UD3R v1.1 - 4GB (2x2) OCZ Reaper HPC DDR2 1066 CL5 2.1v Corsair TX-750w
Gamer: Asrock Z77 Extreme4, i7 3770K @4.6GHz, ThermalTake Armor A90 modded, 2x4GB GSKILL RipjawsX DDR3 2133 CL9, Corsair HX-750w, MSI GTX660 Twin Frozr
Server2012: Q9300 - 8GB DDR2 - Asus P5QL Pro - Corsair CX430 - Mirrored 2TB Seagate's with 2TB WD cav for fileshare backups, 1TB WD for OS backups

DragonFury
Legit Extremist
Legit Extremist
Posts: 605
Joined: Mon Jan 31, 2011 11:51 am

Re: ECS X79R-A Motherboard At Computex 2011 - Pictures Insid

Post by DragonFury » Sat Jun 11, 2011 10:40 am

bubba wrote:This board is going to make case selection easy, nothing with a shallow depth that is for sure. With the CPU that far forward on the board, and fat heatsink like the Noctua NH-D14, you will be very close to the back of the optical drives on a shallow depth case.

Or use an inverted motherboard for the new 2011 CPUs
